Images are for reference only

ADG609BNZ

Name: ADG609BNZ
Rating: 4.7 (12 reviews)

IC MULTIPLEXER DUAL 4X1 16DIP

+BOM RFQ

100% Original & New

24 Hours ready to ship

365 Days Warranty

RFQ & Get more Discounts

Specifications

Package	Bulk,Tube
ProductStatus	Active
SwitchCircuit	SP4T
Multiplexer/DemultiplexerCircuit	4:1
NumberofCircuits	2
On-StateResistance(Max)	30Ohm
Channel-to-ChannelMatching(ΔRon)	5Ohm (Max)
Voltage-SupplySingle(V+)	3.3V ~ 5V
Voltage-SupplyDual(V±)	±5V
SwitchTime(TonToff)(Max)	75ns, 45ns
ChargeInjection	6pC
ChannelCapacitance(CS(off)CD(off))	9pF, 20pF
Current-Leakage(IS(off))(Max)	500pA
Crosstalk	-85dB @ 100kHz
OperatingTemperature	-40°C ~ 85°C (TA)
MountingType	Through Hole
Package/Case	16-DIP (0.300, 7.62mm)
